P8 Platinum Series DOOH LED
DOOH LED Display Solutions
Long-Distance Platinum Series DOOH LED Display
Outdoor Advertising, Commercial Billboards, Stadium Media, Large Outdoor Displays
P8 Platinum Series DOOH LED
Aluminum Profile Cabinet, Outdoor IP65 LED, High Refresh Technology
Transforming Outdoor Advertising with Platinum DOOH LED Displays
Our P8 Platinum Series DOOH LED Display is engineered for outdoor advertising environments requiring lightweight cabinet structures, powerful brightness, and reliable long-distance visibility. Designed for commercial billboards, stadium media systems, large outdoor displays, and branding installations, it delivers stable visuals with seamless playback across demanding outdoor conditions.
Built with advanced aluminum profile cabinet systems and high-performance outdoor LED technology, this display ensures efficient heat dissipation, lightweight structural performance, and long-term operational stability. Its high refresh rate and wide viewing angles provide smooth and flicker-free visuals ideal for large-scale digital advertising applications.
| Parameter | P8 |
|---|---|
| Pixel Pitch | 8 mm |
| LED Type | SMD 3535 |
| Pixel Density | 15,625 pixels/m² |
| Pixels Per module | 60*40 |
| Module Size | W480mm×H320mm |
| Pixels Per Panel | 120*120 |
| Panel Size | W960 mm×H960 mm×D91.9mm |
| Weight | 23kg/panel |
| Maintenance | Front and Rear |
| Ingress Protection | IP66/IP66 |
| Planeness | ≤0.3mm |
| Recommended Viewing Distance | ≥5.71m |
| Material | Die-casting |
| Brightness | 7000/8000/10000 cd/m² |
| Brightness Control | Manual/Automatic |
| Viewing Angle (Horizontal / Vertical) | 140°/120° |
| Contrast Ratio | 5000:1 |
| Gray scale | 14-16 Bit |
| Max Power (W/m2) | 1000 Watt |
| Input Voltage | 100-240VAC |
| LED Life Time | 100,000 Hours |
| Refresh Rate | ≥3,840 Hz |
| Video Frame Rate | 50/60 Hz |
| Operating Temperature/Humidity | -20℃~+50℃ / 10~90%RH |
| Storage Temperature/Humidity | -40℃~+60℃ / 10~90%RH |
Engineered for High-Performance DOOH Applications
The P8 Platinum Series DOOH LED Display is optimized for large-scale outdoor advertising environments requiring lightweight cabinet systems and stable continuous operation. It delivers reliable performance across demanding outdoor media installations.
- Long-distance pixel pitch for powerful outdoor advertising visibility
- High brightness ensures strong daylight display performance
- Aluminum profile cabinet improves lightweight structural efficiency
- High refresh rate ensures smooth advertising playback quality
- Energy-efficient system supports reliable continuous operation
Use Case / Content Display
- Outdoor billboards (example: commercial advertising displays)
- Stadium media (example: sponsor branding systems)
- Commercial facades (example: outdoor media wall installations)
- Smart city advertising (example: public digital communication displays)
- Promotional campaigns (example: large outdoor branding displays)
Tech Stack / Spec Style
Specifications
- Pixel Pitch: 8 mm
- Brightness: ≥6500 nits
- Refresh Rate: ≥3840Hz
- Viewing Distance: ≥8 meters
- Cabinet Type: Aluminum Profile Cabinet
- Power Consumption: 300W (avg)
Final Feature Block
- Designed for large-scale outdoor DOOH advertising installations
- High brightness ensures exceptional outdoor viewing visibility
- Lightweight aluminum profile cabinet improves installation efficiency
- Seamless visuals with high refresh playback quality
- Modular cabinet system supports scalable advertising installations
Engineered for Global LED Excellence
- Global manufacturing expertise across China and India ensuring quality
- Advanced LED components deliver high brightness and color accuracy
- High refresh rate ensures smooth and flicker-free visuals
- Precision PCB and IC engineering ensure stable display performance
- Durable cabinet structures designed for long-term reliable performance
- Energy-efficient systems reduce power consumption and operational costs
- Modular LED design enables flexible installation and scalability
- Consistent visual output ensures uniform brightness and seamless viewing
