P3.07 High-Resolution Outdoor LED Display
Outdoor LED Display Solutions
High-Resolution Outdoor LED Display
Advertising, Retail Branding, Smart City Installations
P3.07
SMD1415 / SMD1921, Outdoor IP65 Cabinet, High Refresh LED
Transforming Outdoor Spaces with High-Resolution LED Displays
Our P3.07 outdoor LED display is designed for outdoor environments requiring ultra-clear visuals, closer viewing distances, and reliable weatherproof performance. Ideal for DOOH advertising, retail branding, and smart city installations, it delivers vibrant visuals with stable and seamless operation.
Built with advanced outdoor LED technology and a rugged IP65-rated cabinet structure, this display ensures long-term durability, energy efficiency, and dependable performance across varying outdoor conditions. Its ultra-high refresh rate and wide viewing angles provide smooth and flicker-free visuals even under direct sunlight.
| Parameters | Specifications |
|---|---|
| Placement(Outdoor) | Outdoor (MS/Die Cast - IP65) |
| Pixel Pitch(mm) | 3.07mm2 |
| LED Configuration | SMD 3 in 1 |
| Light type | SMD1921 |
| rowspan | 1R1G1B |
| Module or Lamp make | LAMP / Hikvision / Qiangli / Changli / GKGD / Leyard |
| Driver IC | ICN / FM / SM /MBI |
| Module Size(mm) | 320*160 |
| Module Resolution(dot) | 104x52 |
| Module Pixel | 5408 |
| Best View distance | ≧4m |
| Brightness | ≥4500cd/m2 |
| View Angle | H≥160° & V≥140° |
| Gray Level | 14-16 bit |
| Refresh Rate | >3840 - ≥7680Hz |
| Driving Mode | 1/13 Scan |
| Refresh frame frequency | 50~60Hz |
| Power Comsumption(max/sqm) | 744W/m2 |
| Power Comsumption(Avg) | 372W/m2 |
| Runing Temperature | –20℃～70℃/RH |
| Storage Temperature | –35℃～+80℃ |
| Humidity | 10% ～95% |
| Lifespan | 100,000H |
| Module size | 320mm×160mm×18mm |
| Weight | 430±5g |
| Contrast ratio | 8000:1, |
| Working voltage | 5V |
| Maximum current of module | 7.5A |
| Average power of module | 19W |
| Maximum power of Module | 38W |
Engineered for High-Performance Outdoor Applications
The P3.07 LED display is optimized for outdoor environments requiring sharp visuals and close viewing clarity. It delivers high brightness, seamless visuals, and reliable performance across premium outdoor installations.
- High-resolution pixel pitch for ultra-clear outdoor visibility
- High brightness ensures visibility under direct sunlight conditions
- Smooth visuals with ultra-high refresh rate technology
- Rugged IP65 cabinet structure for outdoor durability
- Reliable performance with energy-efficient operation systems
Use Case / Content Display
- Advertising (example: premium city advertising displays)
- Retail branding (example: luxury storefront LED screens)
- Smart city installations (example: public information displays)
- Commercial branding (example: high-resolution outdoor signage)
- Event promotions (example: outdoor campaign display walls)
Tech Stack / Spec Style
Specifications
- Pixel Pitch: 3.07 mm
- Brightness: ≥5500–6500 cd/m²
- Refresh Rate: ≥3840Hz – 7680Hz
- Viewing Distance: ≥3 meters
- Module Size: 320 × 160 mm
- Power Consumption: 280W (avg)
Final Feature Block
- Optimized for premium outdoor advertising applications
- High brightness for exceptional daylight visibility performance
- Durable weatherproof structure for reliable outdoor operation
- Seamless visuals with stable refresh rate performance
- Flexible modular design for scalable outdoor installations
Engineered for Global LED Excellence
- Global manufacturing expertise across China and India ensuring quality
- Advanced LED components deliver high brightness and color accuracy
- High refresh rate ensures smooth and flicker-free visuals
- Precision PCB and IC engineering ensure stable display performance
- Durable cabinet structures designed for long-term reliable performance
- Energy-efficient systems reduce power consumption and operational costs
- Modular LED design enables flexible installation and scalability
- Consistent visual output ensures uniform brightness and seamless viewing
