P1.5 Fine Pitch Indoor LED Display
Service
Indoor LED Display Solutions
Indoor LED Display Solutions
Category
Ultra Fine Pitch LED Display
Ultra Fine Pitch LED Display
Application
Corporate Boardrooms, Retail Stores, Experience Centers
Corporate Boardrooms, Retail Stores, Experience Centers
Model
P1.5
P1.5
Technology
SMD1212, Die-Cast Aluminum, High Refresh LED
SMD1212, Die-Cast Aluminum, High Refresh LED
Transforming Indoor Spaces with High-Resolution LED Displays
Our P1.5 indoor LED display is designed for premium indoor environments requiring high clarity and smooth visual performance. Ideal for corporate spaces, retail environments, and experience centers, it delivers sharp visuals, vibrant colors, and seamless viewing.
Built with advanced LED technology and a robust die-cast aluminum cabinet, this display ensures durability, energy efficiency, and easy maintenance. With high refresh rates and excellent color uniformity, it provides a flicker-free and immersive visual experience.
| Parameter | Specification |
|---|---|
| Placement | Indoor |
| Pixel Pitch(mm) | 1.5 mm |
| LED Configuration | SMD 3 in 1 |
| Light type | SMD1212 |
| rowspan | 1R1G1B |
| Module or Lamp make | LAMP / Hikvision / Qiangli / Changli / GKGD / Leyard |
| Driver IC | ICN / FM / SM /MBI |
| Module Size(mm) | 320×160 |
| Module Resolution(dot) | 208×104 |
| Module Pixel | 21632 |
| Pixel Density (dots/m²) | 422500 |
| Best View distance | ≧1.5m |
| Brightness | 600–900 |
| View Angle | H≥160° & V≥140° |
| Gray Level | 16 bit |
| Refresh Rate | 3840 -7680 |
| Driving Mode | 1/52. |
| Refresh frame frequency | 60 Hz |
| Runing Temperature | 10°C to +40°C |
| Storage Temperature | -20°C to +60°C |
| Humidity | 10% – 60% RH |
| Lifespan | 100,000H |
| Weight | 0.45 kg |
| Contrast ratio | ≥5000:1 |
| Working voltage | 5V |
| Maximum current of module | 25 W |
| Average power of module | 8 W |
Engineered for High-Performance Indoor Applications
The P1.5 LED display is optimized for indoor environments that require detailed visuals and close viewing comfort. It ensures reliable performance, excellent brightness, and consistent output across multiple applications.
- Fine pixel pitch for clear close-range viewing
- High brightness with uniform color performance
- Smooth visuals with 3840Hz refresh rate
- Durable die-cast aluminum cabinet design
- Full front service for easy maintenance
USE CASE / CONTENT DISPLAY
- Retail branding (example: premium showroom displays)
- Corporate meetings (example: presentation screens)
- Experience centers (example: product demo walls)
- Digital signage (example: indoor advertising screens)
- Live video and content streaming
TECH STACK / SPEC STYLE
Specifications
- Pixel Pitch: 1.5 mm
- Brightness: 700 nits
- Refresh Rate: 3840 Hz
- Viewing Distance: 1.5–2 meters
- Panel Size: 640 × 480 mm
- Power Consumption: 130W (avg)
FINAL FEATURE BLOCK
- High clarity visuals for professional indoor environments
- Energy-efficient performance with stable operation
- Seamless display with wide viewing angles
- Centralized content management system support
- Flexible modular installation design
ENGINEERED FOR GLOBAL LED EXCELLENCE
- Global manufacturing expertise across China and India ensuring quality
- Advanced LED components deliver high brightness and color accuracy
- High refresh rate ensures smooth and flicker-free visuals
- Precision PCB and IC engineering ensure stable display performance
- Durable cabinet structures designed for long-term reliable performance
- Energy-efficient systems reduce power consumption and operational costs
- Modular LED design enables flexible installation and scalability
- Consistent visual output ensures uniform brightness and seamless viewing
